Mecca Shower Mixer Divertor System Separate Back Plate Gun Metal - NR221912FGM

Regular price $809.60
Regular price $1,012 Sale price $809
Sale Sold out
Tax included. Shipping calculated at checkout.
Are you a trade member? Sign in for trade orders.

Need a Quote?

Generate a quote for this product by adding your email below OR generate a quote based on all items in your cart


Create Quote

  • Single function metal hand piece
  • 2 way divertor switch between hand piece and a second connected outlet
  • 35mm ceramic disc cartridge
  • Packed Separately (Body and Trim Kits)
  • WELS Rating: 7.5L/Min, 4 Star
  • WELS Registration No:S17398
  • Material: Brass
  • More options available, see Avail or Nero’s website
View full details

Description

  • Single function metal hand piece
  • 2 way divertor switch between hand piece and a second connected outlet
  • 35mm ceramic disc cartridge
  • Packed Separately (Body and Trim Kits)
  • WELS Rating: 7.5L/Min, 4 Star
  • WELS Registration No:S17398
  • Material: Brass
  • More options available, see Avail or Nero’s website


Install Advice:

Installation Instruction For Shower System Trim Kits Only:

1. Drill a Ø50mm hole and two 30mm holes into the ceramic tile, then proceed to install the ceramic.

2. Remove the water testing plug

3. Put gauge onto the outlet as above picture. And cut off remaining thread using the provided gauge as a guide.

4. Remove the gauge, self-tapping screw, washer, and plastic sleeve in sequence.

5. Insert the O ring to the dressing bell groove, and slide the dressing bell onto cartridge.

6. Apply waterproof treatment to the three areas.

7. Tighten up the dressing ring on the cartridge bell, and slide divertor cartridge bell onto the cartridge.

8. Apply thread sealant or Teflon tape to the outlet thread, then use a wrench to tighten the outlet onto it.

9. Install the plate, washer, and bracket onto the outlet body.

Installation Instruction For Shower System Trim Kits Only:

10. Slide plate onto body, attach the washer to the cartridge, position the handle, tighten it with a grub screw using an Allen key, and cap the grub screw hole.

11. Slide plate onto body, position the diverter knob , tighten it with a grub screw using an Allen key, and cap the grub screw hole.

12. Connect the hand shower to the bracket with the hose.

13. TEST & CHECK FOR LEAKS.

Assembly and CAD

Installation Guide Mecca Shower Mixer Divertor System Separate Back Plate

Download

3D CAD BIM Mecca Shower Mixer Divertor System Separate Back Plate

Download
