i. Meets all AS1428.1 Section 12 Compliance requirements for DDA Accessible Toilets (when combined with contrasting wall or floor colour)
ii. 800mm to front edge 460mm Seat Height
iii. Seat is White, to meet AS1428.1-2021 minimum 30% luminance colour contrast requirement the wall or floor must contrast at least 30% (for grey seats the contrast against the toilet suite is sufficient)
i. Additional Products required for AS1428.1-2021 Accessible Toilet Compliance (see install diagram for required install locations):
1. Raised Flush Buttons for In Wall Cistern: Toilet Raised Flush Button Panel AS1428.1 DDA Accessible Pneumatic for G30035 Cistern Brushed Nickel - NRCRPL002BN
2. In Wall Cistern Pneumatic: In Wall Cistern Concealed for NRCRPL002 AS1428 Pneumatic Raised Flush Buttons - G30035
3. Toilet Backrest: Calibre Mecca DDA Accessible Toilet Backrest Removable Brushed Nickel - NRCR0001BN
4. Accessible Toilet Side Grab Rail 90 or 45 degree: Calibre Mecca 32mm DDA Accessible Grab Rail Set 90 Degree 600x1000mm Brushed Nickel - NRCR3290BN or Calibre Mecca 32mm DDA Accessible Toilet 90 Degree Grab Rail 600x1000mm Brushed Nickel - NRCR3290eBN
5. Accessible Toilet Rear Grab Rail minimum 300mm length: Calibre Mecca 32mm Grab Rail 300mm Brushed Nickel - NRCR3212BN
6. Toilet Roll Holder Single or Double (other options are available): Calibre Mecca Add On Toilet Roll Holder Brushed Nickel - NRCR3286TBN or Mecca Double Toilet Roll Holder Brushed Nickel - NR1986dBN
- Versatile and Adaptable: Ideal for a wide range of settings, including commercial buildings, public spaces, and residential properties.
- Our accessible toilets can be customized to meet specific needs and seamlessly integrate into any environment.
- Highest Quality
- Vitreous China Construction
- Rimless Flushing Technology
- Heavy Duty Duraplast
- Quick Release
- Soft Close Seat
- WELS Registration No. L08200
- WELS Licence No. 0422
- Average flush: 3.5 Litres, Full flush: 4.5L, Half flush: 3.1L
- Star Rating: WELS 4 Star
- Warranty: 7 year replacement product or parts*:1 year labour
*Excludes valves, seats, button assembly, links, flush pipes & other internal components which carry a 1 year replacement warranty - Formerly Code: HDC692-HEBTW
- Standard P Trap
- Supplied with S-trap adaptor to suit 130-260mm Set Out.
- Will Suit 190-360mm Set Out with S-TRAP2 (sold separately)
- Size: 360mm x 800mm x 430mm
